SCPC-SCPC DUPLEX SINGLE MODE ARMORED PATCH CORD
Key Features
- High-quality materials and construction
- Industry standard compliance
- Rigorous quality testing
High-Density LC Fiber Optic Patch Cord Solution
Telhua's SCPC-SCPC Duplex Single Mode Armored Patch Cord delivers exceptional reliability in high-density data center and enterprise network environments. Engineered for precision connectivity, this armored LC patch cord eliminates common installation challenges while maintaining superior optical performance.
Addressing Critical B2B Infrastructure Challenges
Network architects and data center managers face persistent challenges in modern fiber deployments:
- Space Optimization: Maximize port density without compromising cable management or airflow
- Installation Efficiency: Reduce deployment time while maintaining termination quality
- Long-Term Reliability: Prevent signal degradation and physical damage in demanding environments
- Standards Compliance: Ensure interoperability across multi-vendor ecosystems
Telhua Engineer's Tip: Armored Cable Bend Radius Optimization
When deploying armored patch cords in high-density panels, maintain a minimum bend radius of 15 times the cable diameter (15D) rather than the standard 10D. This additional margin compensates for the armored layer's reduced flexibility and prevents micro-bending losses that can accumulate to 0.1dB over time. For our 2.0mm armored cords, this translates to a 30mm minimum bend radius—critical for maintaining single-mode performance specifications in constrained spaces.
Technical Specifications
| Parameter | Specification | Standard |
|---|---|---|
| Connector Type | LC Duplex | IEC 61754-20 |
| Fiber Type | Single Mode OS2 | ITU-T G.652.D |
| Insertion Loss | ≤0.2 dB | TIA/EIA-568-3-D |
| Return Loss | ≥55 dB (PC), ≥65 dB (APC) | IEC 61300-3-6 |
| Cable Diameter | 2.0 mm ± 0.1 mm | IEC 60794-2-50 |
| Armor Material | Corrugated Steel Tape | RoHS Compliant |
| Operating Temperature | -40°C to +85°C | IEC 60793-2-50 |
| Pull Strength | 200 N (Installation), 100 N (Operational) | TIA-455-33-B |
| Flammability Rating | OFNR/OFNP Available | UL 1666/UL 910 |
Standards Compliance & Quality Assurance
Every Telhua armored LC patch cord undergoes rigorous testing to ensure compliance with international standards. Our manufacturing process adheres to IEC 61300-3-34 for polarization maintaining fiber testing, TIA/EIA-455-171 for cable flex endurance, and RoHS directives for environmental safety. Each unit is 100% optically tested with traceable certification.
