sc apc patch cord
Key Features
- High-quality materials and construction
- Industry standard compliance
- Rigorous quality testing
High-Density SC APC to LC Patch Cord Solutions
Telhua's SC APC to LC patch cords deliver exceptional performance in demanding B2B environments where space optimization, signal integrity, and rapid deployment are critical. Engineered with precision-polished APC (Angled Physical Contact) connectors, these cords minimize back reflection to below -65dB, ensuring reliable data transmission in high-speed networks. Our cords address common infrastructure challenges by enabling efficient cable management in densely populated racks while maintaining superior optical performance.
Optimized for Enterprise and Data Center Applications
These duplex patch cords feature Telhua's proprietary low-loss ceramic ferrules and strain relief boots that protect against accidental disconnection. The SC APC to LC configuration provides flexibility in connecting different interface types commonly found in telecommunications, enterprise networks, and data center environments. Each cord undergoes rigorous testing to guarantee insertion loss below 0.2dB and return loss exceeding 65dB.
Technical Specifications
| Specification | Value |
|---|---|
| Connector Type | SC APC to LC UPC |
| Fiber Type | Single-mode OS2 |
| Insertion Loss | ≤ 0.2 dB |
| Return Loss | ≥ 65 dB |
| Operating Temperature | -40°C to +85°C |
| Cable Diameter | 2.0 mm / 3.0 mm |
| Available Lengths | 0.5m, 1m, 2m, 3m, 5m, 10m, custom |
| Compliance Standards | IEC 61754, TIA/EIA-604, RoHS |
Telhua Engineer's Tip
For optimal performance in high-density installations, utilize our 2.0mm diameter cables with 90-degree angled SC APC connectors. This configuration reduces bend radius stress while maximizing port accessibility in constrained spaces. Our proprietary polishing technique creates a consistent 8-degree angle across all connectors, ensuring uniform mating surfaces that maintain specified return loss values through thousands of connection cycles.
Standards Compliance and Quality Assurance
Every Telhua SC APC to LC patch cord meets or exceeds international standards including IEC 61754 for connector interfaces, TIA/EIA-604 for performance requirements, and RoHS directives for environmental safety. Our manufacturing process incorporates 100% optical testing with automated inspection systems that verify each connector's endface geometry and surface quality before shipment.
Addressing B2B Infrastructure Challenges
- Space Optimization: Slim-profile connectors and flexible cable designs enable higher port density in patch panels
- Installation Efficiency: Color-coded strain relief boots and push-pull latching mechanisms reduce deployment time by up to 40%
- Long-term Reliability: Corrosion-resistant zirconia ceramic ferrules maintain optical performance in varying environmental conditions
- Interoperability: Compatible with all major OEM equipment using SC APC and LC interfaces
