Preterminated OSP Terminals and Drops
Product Parameters
- Indoor / Outdoor:Indoor
- Lockable:Yes
- Material:Metal
- Outdoor Connector:No
Optimize Your Fiber Network with Preterminated OSP Terminals and Drops
Telhua's Preterminated OSP Terminals and Drops deliver a complete, factory-tested solution for outdoor fiber distribution. Engineered for rapid deployment and exceptional reliability, these systems eliminate field termination errors and reduce installation time by up to 70% compared to traditional methods. Our high-density designs maximize port utilization in limited spaces, while robust, weatherproof construction ensures consistent performance in harsh environments from -40°C to 85°C.
Key Benefits for Network Operators
- Accelerated Deployment: Plug-and-play installation minimizes labor costs and network downtime.
- Enhanced Reliability: Factory-polished connectors and tested assemblies guarantee optimal signal integrity.
- Superior Density: Compact footprint supports up to 144 fibers in a single enclosure for space-constrained applications.
- Future-Proof Design: Modular architecture allows easy upgrades and expansions without service disruption.
- Reduced Total Cost of Ownership: Lower installation and maintenance expenses through standardized components.
Technical Specifications
| Parameter | Specification |
|---|---|
| Fiber Capacity | 12 to 144 fibers |
| Connector Type | LC, SC, or MPO (factory-terminated) |
| Insertion Loss | ≤ 0.3 dB (typical) |
| Return Loss | ≥ 55 dB (PC), ≥ 65 dB (APC) |
| Operating Temperature | -40°C to +85°C |
| Ingress Protection | IP68 rated |
| Standards Compliance | IEC 61753-1, TIA/EIA-568-D, RoHS |
Telhua Engineer's Tip
For optimal performance in temperature-fluctuating environments, ensure proper slack storage within the terminal. Coil excess fiber with a minimum bend radius of 30mm (1.2 inches) using our integrated organizers. This prevents microbend-induced attenuation and maintains signal stability across the operating temperature range. Our terminals include pre-installed bend-insensitive fiber for additional margin.
