Opterna 19inch 1U fibre patch panel 24 port
Product Parameters
- Drawer Open Way:Sliding
- Material:Metal
- No. of U:1U
High-Density 24-Port Fiber Optic Patch Panel
Telhua's Opterna 19-inch 1U fiber patch panel delivers maximum port density in minimal rack space, engineered for enterprise data centers, telecom central offices, and high-performance network environments. This 24-port solution addresses critical infrastructure challenges by providing reliable fiber management with superior organization and accessibility.
Engineered for B2B Network Demands
Network managers face constant pressure to optimize rack space while maintaining flawless connectivity. The Opterna patch panel solves these pain points with:
- Space Optimization: 24 LC duplex ports in a single rack unit (1U) maximize density without compromising cable management
- Installation Efficiency: Pre-installed adapter plates and clear port numbering reduce deployment time by up to 40% compared to traditional panels
- Reliability Assurance: Precision-machined components ensure consistent insertion loss below 0.2 dB and return loss exceeding 55 dB
- Future-Proof Design: Modular construction supports easy upgrades from multimode to single-mode applications
Telhua Engineer's Tip: Bend Radius Management
For optimal performance in high-density installations, maintain a minimum bend radius of 30mm for standard fiber and 15mm for bend-insensitive fiber. Our integrated radius limiters provide physical protection, but proper cable routing during installation prevents microbending that can increase attenuation by 0.1-0.3 dB/km. This becomes critical in 40G/100G deployments where link loss budgets are stringent.
Technical Specifications
| Specification | Value |
|---|---|
| Form Factor | 19-inch rack mount, 1U height (44.45mm) |
| Port Configuration | 24 LC duplex ports (48 fibers total) |
| Adapter Type | LC UPC (SC and APC available) |
| Insertion Loss | ≤ 0.2 dB typical, ≤ 0.3 dB maximum |
| Return Loss | ≥ 55 dB (UPC), ≥ 65 dB (APC) |
| Operating Temperature | -40°C to +75°C |
| Fiber Capacity | Supports up to 12mm diameter cables |
| Compliance Standards | IEC 61754, TIA/EIA-604, RoHS compliant |
| Material Construction | Cold-rolled steel with powder coating |
| Weight | 2.8 kg (6.2 lbs) |
Standards Compliance & Quality Assurance
Every Opterna patch panel undergoes rigorous testing to exceed industry standards. Our manufacturing process ensures compliance with IEC 61754 for fiber optic connector interfaces, TIA/EIA-604 for performance requirements, and RoHS directives for environmental safety. Telhua's quality control includes 100% insertion loss verification and mechanical durability testing across 500 mating cycles.
