Outdoor ftth termination box 16 port fiber optic terminal box
Product Parameters
- Indoor / Outdoor:Outdoor
- Lockable:Yes
- Material:Plastic
- Outdoor Connector:No
High-Density Outdoor FTTH Termination Solution
Telhua's 16-port outdoor fiber optic terminal box delivers exceptional port density in a compact, weatherproof enclosure designed for demanding FTTH deployments. Engineered to streamline network expansion while maintaining signal integrity, this termination box addresses critical B2B challenges including space constraints, installation efficiency, and long-term reliability in harsh outdoor environments.
Key Features for Network Professionals
Optimized Installation & Maintenance
Featuring tool-less access and intuitive cable management, this terminal box reduces field installation time by up to 40% compared to conventional designs. The modular tray system allows for individual port servicing without disrupting adjacent connections, minimizing network downtime during maintenance operations.
Superior Environmental Protection
Constructed with UV-resistant engineering polymers and stainless steel hardware, the enclosure maintains IP68-rated protection against dust, moisture, and extreme temperatures (-40°C to +85°C). The integrated drip loop design and hydrophobic gel sealing ensure consistent performance through seasonal weather variations.
Enhanced Signal Management
Precision-molded fiber routing channels with 35mm minimum bend radius protection prevent microbending losses. The color-coded port identification system and clear labeling fields support efficient fiber tracing and reduce documentation errors during network audits.
Technical Specifications
| Specification | Value |
|---|---|
| Port Configuration | 16 SC/APC adapters (field-configurable) |
| Fiber Capacity | Up to 144 fibers (loose tube) or 96 fibers (ribbon) |
| Dimensions | 400mm × 300mm × 120mm (L×W×H) |
| Ingress Protection | IP68 (submersible to 1.5m for 30 minutes) |
| Operating Temperature | -40°C to +85°C |
| Material Construction | PC/ABS composite with 304 stainless steel brackets |
| Installation Options | Pole-mount, wall-mount, or direct burial |
| Compliance Standards | IEC 61753-1, TIA/EIA-568-C.3, RoHS Directive 2011/65/EU |
Telhua Engineer's Tip
For optimal performance in coastal deployments, apply our proprietary anti-corrosion coating (part #TC-247) to all metallic components before installation. This nano-ceramic layer reduces salt spray corrosion by 92% compared to standard galvanized finishes, extending service life in marine environments by 8-10 years. The coating adds minimal thermal resistance (0.02°C/W) while maintaining full EMI shielding effectiveness.
Standards Compliance & Quality Assurance
This fiber optic terminal box meets or exceeds international standards including IEC 61753-1 for environmental performance, TIA/EIA-568-C.3 for optical fiber cabling components, and RoHS Directive 2011/65/EU for hazardous substance restrictions. Each unit undergoes 72-hour accelerated aging tests and optical performance validation before shipment.
