19 inch 1U 48 Ports SC Duplex Adapter Sliding Patch Panel

Engineered for High-Density, High-Reliability Networks

In today's data-driven environment, network infrastructure must balance maximum port density with flawless reliability and ease of maintenance. Telhua's 1U 48-port SC Duplex Sliding Patch Panel is designed to address these core B2B challenges. It consolidates 48 duplex connections in a single rack unit, optimizing valuable data center real estate while providing a robust, organized termination point for your critical fiber backbone.

Key Features & Benefits

Feature	Benefit
1U Rack Space, 48 SC Duplex Ports	Delivers exceptional port density, allowing you to connect more fibers without expanding your rack footprint. Ideal for space-constrained data centers and telecom closets.
Sliding Tray Design	Provides full, unobstructed access to the rear adapters and fiber management. Dramatically reduces installation and maintenance time compared to fixed panels.
Robust Metal Construction	Ensures long-term durability and protects delicate fiber connections. The chassis provides excellent EMI shielding and structural integrity.
Integrated Cable Management	Includes built-in strain relief bars and routing guides to maintain proper bend radius, reduce signal loss, and keep cables organized.

Technical Specifications

Physical & Mechanical

Form Factor: 19-inch Rack Mount, 1U Height (1.75"/44.45mm)
Port Configuration: 48 Ports, SC Duplex (96 fibers total)
Adapter Type: SC/UPC Duplex (Standard)
Panel Type: Sliding / Pull-out Tray
Material: Cold-rolled steel, powder-coated
Color: Black

Performance & Compliance

Insertion Loss: ≤ 0.2 dB
Return Loss: ≥ 55 dB (UPC)
Operating Temperature: -40°C to +75°C
Standards Compliance: IEC 61754-4, TIA/EIA-604-4 (FOCIS 4), RoHS

Telhua Engineer's Tip

Proactive Slack Management for Future-Proofing: When routing fibers into the sliding tray, intentionally leave a service loop of 12-18 inches (30-45 cm) of slack coiled neatly in the rear compartment. This "future-proofing loop" is critical. It allows for multiple re-terminations or connector changes over the panel's lifespan without requiring a complete cable pull from the trunk. This simple step during initial installation can save hours of downtime and labor during future upgrades or repairs.

Applications

This high-density patch panel is the ideal solution for:

Enterprise Data Center Main Distribution Areas (MDA)
Telecom Central Offices and POPs
High-density LAN/SAN cabling
Fiber-to-the-Desk (FTTD) consolidation points
Broadband and CATV headends

Why Choose Telhua?

Telhua combines over 15 years of optical engineering expertise with rigorous manufacturing standards. Every patch panel is 100% factory tested to ensure it meets our stringent performance specifications for insertion loss and return loss. We are committed to providing reliable, standards-compliant solutions that simplify your network deployment and reduce total cost of ownership.
